High Speed Checkweigher for Box-Pack Automatic Check Weigher With T-Push Rejector
This high-speed checkweigher for box-pack is designed for high-speed operation and integrates seamlessly with automated packaging and conveying systems. Its intelligent control software enables real-time weight monitoring, instant feedback, and automatic rejection of defective cases. With its compact footprint and robust construction, automatic check weigher with T-push rejector supports continuous operation while maximizing space utilization and improving production line efficiency in the food, pharmaceutical, and consumer goods packaging industries. Our product specifications and sizes are rich, various styles, welcome to contact us for quotation information.
High-speed checkweigher for box-pack photos
Type SG-100
Weighing Range 2-300g
Limited of product L: 100 W: 100 H: 2-150mm
Accuracy ±0.05g Depends on product
Division Scale 0.01g
Belt Speed 0- 90 m/min
Max Speed 260 pcs/min
Belt Width 100mm
Machine Weight 70kg
Power Supply AC 220V ±10% 50HZ
Power 100W
Main Material SU304 stainless steel
High Speed Checkweigher for Box-Pack Automatic Check Weigher With T-Push Rejector
1. Ease of Use: Large LCD touchscreen display with Chinese and English interface, customizable language settings.
2. Accuracy: High-precision sensors ensure high detection accuracy and speed.
3. Real-time: The graph displays the statistical distribution of sorting results and provides real-time monitoring of sorting dynamics.
4. Memory: Allows for preset sorting parameters for 100 products, enabling quick switching between different products.
5. Automatic Learning: High-speed, high-precision digital filtering algorithm with automatic learning of data filtering parameters.
6. Intelligence: Dynamic zero-point tracking, including zero-point tracking during continuous operation, automatically corrects weight values.
7. Reliability: Variable frequency motor drive effectively improves equipment stability.
8. Data: Preset data transmission interface allows for setting or exporting product sorting parameters via USB.
9. Accuracy: Utilizes photoelectric calibration weighing triggering, effectively improving equipment accuracy.
10. Removal: Multiple removal methods are available to remove overweight or underweight products.
The high-speed checkweigher for box-pack shown may not meet your requirements. We have professional technicians who can provide customized solutions based on your product characteristics and application scenarios.
High-speed checkweigher for box-packs are now widely used in food, pharmaceutical, chemical, machinery and agricultural products industries abroad.
High Speed Checkweigher for Box-Pack Automatic Check Weigher With T-Push Rejector
Internal packaging uses plastic, while the outer packaging will use a more robust wooden crate.
Our standard packaging process:
1) Dust removal and cleaning
2) Lubrication of drive components
3) Disassembling the machine into modules
4) Wrapping modules with plastic film
5) Packing modules into plywood crates
6) Marking the crates with shipping marks.
If there are any special requirements, we will pack accordingly.
For many years, SGWEIGH has been serving customers in the melt industry. Through research and exploration, we have summarized a complete set of product and service support systems to provide users with high-quality and timely pre-sales, sales, and after-sales services:
1. Quality Assurance
Our business department guarantees that the equipment provided to customers is all original production, and the factory information of the parts is complete. To ensure the normal operation and maintenance of the contracted equipment, the technical products provided by our department are complete, clear, and correct.
2. Quality Assurance Measures
Warranty Period: One-year warranty, lifetime maintenance. During the warranty period, non-human-caused damage parts will be replaced free of charge; after the warranty period, parts will be provided at cost price.
