High-Sensitivity Capsule Metal Detector for Pharma Vertical Metal Detector
The high-sensitivity capsule metal detector is equipped with advanced sensors to ensure that every tablet leaving the production line is free of iron, non-ferrous metals and stainless steel contaminants, providing fast and accurate inspection results without interrupting high-speed tablet production. Whether installed before or after filling or before packaging, this capsule tablet vertical metal detector can help pharmaceutical companies maintain the highest standards of safety, consistency and compliance. You are welcome to contact us at any time for quotation.
High-sensitivity capsule metal detector photos
Type: SG-YJ60
Inter Height: H 770-930mm; Port size: φ76mm
Outer Height: H 770-860mm; Port size: φ51mm
Effective passing size: W70*H20mm
Output Capacity: 50w pcs/h
Detection sensitivity: φ Fe 0.4mm;φ SUS 0.6mm
Deadweight of machine: 75kg
Rejection Way: Flip Culling
Working powder supply: 220v/110v, 50/60Hz
Dimension: 1115*550*(1280-1440)mm
High-Sensitivity Capsule Metal Detector for Pharma Vertical Metal Detector
1. The most advanced microcomputer control system with self-learning function.
2. The height and tilt angle of the manual lift table can be easily moved and cleaned, and lockable casters are installed
3. The main control components are all imported. The control menu adopts a one-button operation mode, which is easy to operate and has Chinese/English operation menus. The metal detector can memorize and supplement its functions. It has 200 product storage and 1000 accidental memories.
4. Open design, parts in contact with the product can be removed without tools within 10 seconds. No dead angle, easy to clean and wash.
5. The high-sensitivity capsule metal detector has a full body safety structure with no dead angle. The power supply is a safe 24V voltage.
6. Completely independent sensor system. Tool-free disassembly, easy maintenance and cleaning.
7. Independent control system, connected to the sensor system through a modular air plug.
8. Independent rejection unit through quick connection. No air source required.
9. Working voltage: 220/110VAC (+10%, -15%)
10. Suppression time 0.05-60 seconds adjustable
11. Protection level: IP65.
The high-sensitivity capsule metal detector on display may not meet your requirements. We can customize it according to the different usage requirements of users to perfectly solve the metal detection problem of the production line.
1. Pharmaceutical capsule and tablet production
2. Nutritional supplement production
3. High-speed, high-volume production lines
High-Sensitivity Capsule Metal Detector for Pharma Vertical Metal Detector
1. Packaging materials: Usually international standard export packaging boxes are used, which have good wear resistance, shock resistance and waterproof performance. The box material can be hard wooden boxes, plastic boxes or export-specific cartons.
2. Protective measures: To ensure that the machine is not damaged during transportation, it is necessary to add sufficient filling materials such as foam, shockproof cotton, etc. in the packaging box.
1. Equipment installation and commissioning: The company provides a detailed operation manual and free operation training so that customers can master the use of the equipment.
2. Technical support: The company provides 7×24 hours of technical support. Customers can contact engineers at any time to solve any problems encountered during use.
3. Accessories supply: The company provides original accessories to ensure the quality and stability of accessories.
4. Quality assurance: The company is responsible for the products sold and ensures that the quality and performance of the equipment meet industry standards.
5. One-year warranty, lifetime maintenance
